Snapmaker 1064NM Infrared Laser Module Series
Compatible Series
• Snapmaker 2.0 A350T/A350/F350
• Snapmaker 2.0 A150/A250T/A250/F250
• Snapmaker Artisan/Ray
Unlock More Possibilities
The Snapmaker 1064nm Infrared Laser Module is compatible with the Rotary Module, Air Purifier, Enclosure, Quick Swap Kit, Emergency Stop Button, and Bracing Kit.
With such convenient and fun Laser Engraving, don't you want to engrave out your ideas? Contact Us for more details of Snapmaker and information of Laser Engraving!
| Laser Output Power |
2W |
| Laser Electric Power |
40W |
| Laser Type |
1064nm Infrared Laser |
| Dimensions (W x D x H) |
92mm x 73mm x 126mm |
|
 |
| Weight |
0.8kg |
| Maximum Work Speed |
Snapmaker 2.0: 100mm/s
Artisan: 200mm/s
Ray: 600mm/s |
| Work Area |
150mm x 150mm (A150-With Quick Swap Kit)
140mm x 150mm (A150-Without Quick Swap Kit)
240mm x 250mm (A250-With Quick Swap Kit)
240mm x 230mm (A250-Without Quick Swap Kit)
340mm x 350mm (A350-With Quick Swap Kit)
340mm x 330mm (A350-Without Quick Swap Kit)
400mm x 400mm (Artisan)
600mm x 400mm (Ray) |
| Supported Engraving Materials |
Gold, Silver, Copper, Titanium, Iron(incl.Stainless steel), Aluminum, Chromium, ABS, ABS(3D Printing), PLA(3D Printing), HIPS(3D Printing), PETG(3D Printing), Acrylic(Non-transparent), PET, etc. Leather, Silicone (non-transparent), PCB |
