Polymaker PolyMax™PC-FR Black
Industrial grade materials can be used to 3D print new applications in a variety of industries. Industrial products may require specific equipment and skills and PolyMax™, a range of high-end 3D printing consumables produced using Polymaker's nano-enhanced technology, offers excellent mechanical properties and print quality.
PolyMax™ PC-FR, produced using Costco's Makrolon® range, achieves V0 performance in the UL94 flammability test and has excellent toughness, strength and heat resistance. It opens up new applications in the automotive, rail and aerospace industries.
| Nozzle Temperature |
250?C–270?C |
| Printing Speed |
30 – 50mm / s |
| Bed Temperature |
90?C–105?C |
| Chamber Temperature |
90?C–100?C |
| Recommened Bed Surface |
PolyMax™ PC-FR can be printed on almost any surface with a thin coat of PVA or Magigoo PC. |
| Cooling Fan |
OFF
Based on 0.4mm nozzle and Simplify 3D v.4.0.
Printing conditions may vary depending on printer and nozzle diameter. |
| Young's Modulus |
2634±182（MPa） |
| Tensile Strength |
67±4.5（MPa） |
| Bending Strength |
96.6±1.3 |
| Charpy Impact Strength |
11.7±1.6（kJ / m2） |
| Crystallizaion Temperature |
N / A |
| Vicat Softening Temperautre |
116?C |
| Melting Temperature |
N / A |
| Glass Transition Temperature |
115?C |
| Note |
- When printing with PolyMax™ PC-FR, it is recommended to use an enclosure.
For large part, it is recommended to use a heated chamber.
- It is recommended to anneal the printed part right after the printing process to
release the residual internal stress. Annealing settings: 90?C for 2h |
